OM1602-11
昂瑞微 射频芯片 低噪声放大器 OM1602-11
The OM1602-11 consists of three groups of LNA and switch combinations that support multi-mode RF front-end modules for wireless. The OM1602 is compatible with MIPI RFFE V3.0 control interface.
This OM1602 packaged in a small LGA2.9mm ×2.9mm package. A functional block diagram isshown in Figure1.
• Broadband frequency range:
- Low band(LB) supported from 600 to 960MHz
- Middle High Band(MHB) supported from 1800 to 2700MHz
• 3 LNA output groups with path selections and MHB output mux
- 1 LB group
- 2 MHB groups
• Designed for CA operation and LNA paths co-existence. MIPI RFFE V3.0 compatible
• Compact, LGA (49-pin, 2.9mm x 2.9mm x 0.75mm) package, MSL3
• 5G smartphones and tablets
• 5G data cards
• Supports downlink CA and MIMO application
