HS8775C-16

昂瑞微射频芯片天线调谐开关 HS8775C-16

产品描述

产品特征

应用

The HS8775C-16 is a single-pole four-throw (SP4T) switch designed for antenna/impedance tuning applications which requires very low insertion loss and high voltage handling capability. It can also be used for multi-mode GSM/GPRS/EDGE/WCDMA/LTE transmit/receive applications. The HS8775C-16 is controlled by a standard GPIO interface for easy control. The HS8775C-16 includes an integrated LDO (Low Drop Out) regulator, which enables operation over a very wide supply range. No need for external DC blocking capacitors unless DC is applied externally. The HS8775C-16 is manufactured in a compact, 10- pin 1.1 x 1.5 x 0.40 mm package.

• Excellent insertion loss: 0.50 dB at 2.7 GHz

• High peak voltage handling: 60 V

• Low Ron and Coff

• No DC blocking capacitors required

• Small package: LGA-10 1.1 x 1.5 x 0.40 mm
