OM6621P

The OM6621Px is a power-optimized true system-on-chip (SOC) solution for both Bluetooth low energy and proprietary 2.4GHz applications. It integrates a high performance and low power RF transceiver with Bluetooth base band and rich peripheral IO extension.OM6621Px also integrates a power management to provide high-efficient power management. It targets 2.4GHz Bluetooth low energy systems, proprietary 2.4GHz systems, Human-Interface Devices (smart watch, bracelets, smart lock, smart switch,etc.), sports and leisure equipment, mobile phone accessories and consumer electronics.

OM6621Px on-chip Bluetooth system support BLE5.1 full feature.

The chip integrates up to 128MHz high-performance MCU, GPIO, DMA, UART, I2S, I2C, SPI, Timer, RTC, Watchdog, PIC_DEC, supports 32MHz external crystal, integrates multi-purpose 12-bit ADC.

The OM6621Px supports user defined IDE system on chip SFLASH MCU development and JTAG software upgrade.

• RF transceiver
  •         -96dBm sensitivity @1Mbps
  •         -93dBm sensitivity @2Mbps
  •         -99dBm sensitivity @500Kbps
  •         -102dBm sensitivity @125Kbps
  •         TX power -20 ~ +9dBm
  •         Fast Automatic gain Control circuit (AGC)
  •         RSSI (1db resolution)

• CPU
  •         ARM® Cortex™-M4F, max 128MHz
  •         Serial Wire Debug (SWD)

• Memory
  •         392KB SRAM
  •         ICACHE 16K-4way
  •         SFLASH
  •         OM6621PG/PG-U/PH: 1MB
  •         OM6621PWPG-S: 2MB

• Clocks
  •         32MHz crystal, 32MHz RC, 32.768KHz crystal, 32.768KHz RC
  •         Link Controller
  •         BT 5.1 LE PHY, link controller
  •         Proprietary 2.4-GHz link controller

• Power Management
  •         Supply voltage range
  •         OM6621PG/PW: 2.7V ~ 3.6V
  •         OM6621PG-U/PG-S/PH: 1.8V ~ 3.6V
  •         Peak operating current, RX 6.8mA, TX 6.4mA (+ 0dBm)
  •         Deep sleep current 5.8uA (RC32K on, 256KB RAM retention)
  •         Ultra sleep current 1.6uA (no RC32K, no RAM)
  •         Integrated DCDC BUCK Converter
  •         Integrated Lithium Battery Charging Function (100mA/300mA, only OM6621PH is not supported this function )
  •         OM6621PG/PG-U/PG-S: all IO support 3.3V
  •         OM6621PW/PH: all IO support 3.3V, and partial IO support 1.8V

• Software
  •         Power optimized link layer firmware and protocol stack
  •         Supports Bluetooth mesh standard network
  •         Supports multiple BLE profiles and application examples
  •         Supports HCI Controller Interface
  •         Supports 6LowPAN
  •         Supports OTA
  •         SWD interface
  •         Supports Free Rtos

• Peripherals
  •         OM6621PG/PG-U/PG-S support 31 GPIOs + 2 Input IOs
  •         OM6621PW support 47 GPIOs + 3 Input IOs
  •         OM6621PH support 48 GPIOs + 3 Input IOs
  •         4 channels DMA
  •         Supports QSPI LCD
  •         Supports QSPI PSRAM
  •         2 x UART, one of them is compatible with ISO7816
  •         1 x I2S interface
  •         3 x I2C interface
  •         2 x SPI interface
  •         3 x Timer/Counter with 4 Compare/Capture/PWM channels
  •         RTC
  •         WDT
  •         Keyboard Controller
  •         3 x QDEC
  •         single-end/differential 8-channel 12-bit, up to 16Msps (precision and sample rate can be configured)
  •         Audio ADC
  •         16-bit ADC
  •         support PDM, IIS
  •         SNR 93dB
  •         The PINMUX will freely configure all types of interfaces

• Security and Encryption
  •         AES HW encryption(Integrated in the Bluetooth module)
  •         Support AES-128 key
  •         Support encryption mode
  •         True random number generator

• Package and Work Environment
  •         OM6621PG/PG-U/PG-S: 48-pin 6x6mm QFN48
  •         OM6621PW: 64-pin 7.5x7.5mm QFN64
  •         OM6621PH: 76-pin 3.5x5mm BGA76
  •         -40 ℃~+85 ℃

The OM6621Px integrated circuit has a fully integrated radio transceiver and base band processor for Bluetooth® Smart. It can be used as an application processor as well as a data pump in fully hosted systems.
