OM9385-11

OM9385-11 is a multi-mode, high efficiency Low Band, Mid Band and High Band PAMiD (Power Amplifier Module with integrated Duplexers) module designed for use as the integrated RF front-end in multi-mode NR / LTE / UMTS / CDMA mobile cellular equipment. The high efficiency PAMiD contains power amplifier paths for 3G/4G/5G Low, Mid and High Band frequencies along with distribution switches, multiplex filters, and antenna switches for multi-band coverage of both transmit and receive functions. OM9385-11 band select and operating parameters are programmed through the Mobile Industry Processor Interface (MIPI) bus(es). The OM9385-11 transmit-receive module supports Average Power Tracking (APT) for application versatility combined with higher system efficiency across a wide range of power levels. The OM9385-11 is packaged in a RoHS-compliant, compact 62-pin, 6.5 × 8.6 × 0.8 (max) mm surface-mount leadless package.

•     Multi-Mode and Multi Band Capabilities

•     NR, FDD-LTE/TDD-LTE, WCDMA, CDMA2000

•     Integrated Band 1, 3, 5 ,8, 34, 39, 40 and 41(38) Filters for Transmit and Receive

•     Additional Bands Through External TX/TRX Paths

•     MIPI V2.1 RFFE Digital Control Interface

•     Designed and Optimized for Use with DC-DC Converter

•     Support of Average Power Tracking (APT) for High System Efficiency and Versatility

•     Power Class 3 (PC3)

•     Self-shielding is optional

•     3G/4G/5G Multi-Mode Modems, Handsets, Data Cards or Wearable Devices

•     High Performance Communication Systems
