OM1910-11

The OM1910-11 is a DiFEM integrated with SAW filters and SP7T + SP8T antenna switches. The OM1910-11 covers WCDMA/LTE bands1, 3, 8, 26, 28, 34, 39, 40, 41, and contains 1 LTE Low band _ AUX output and 2 LTE Middle/High Band _ AUX output. The OM1910-11 supports downlink carrier aggregation combinations: B1 + B3, B39 + B41. The OM1910-11 is compatible with MIPI 3.0 RFFE control interface. This part is packaged in a compact LGA 3.0mm x 3.2mm x 0.65mm package. A functional block diagram is shown in Figure 1. The pin configuration are shown in Figure 2. Signal pin assignments and functional pin descriptions are provided in Table 1.

•     L/M/H Rx diversity FEM with the following integrated filter bands: B8, B26, B28, B1, B3, B34, B39, B40, B41

•     Integrated downlink carrier aggregation (CA) support: B1+B3+B40; B1+B3+B41; B39+B41; B40+B41

•     Two additional MHB ASM TRXs

•     One additional LB ASM TRXs

•     High-performance Multi-On, N-Plexing technology enabling superior non-CA and CA performance

•     MIPI RFFE V3.0 compatible

•     Small, LGA (22-pin, 3.0mm x 3.2mm x 0.65mm) package，MSL3

•     Antenna cable loss compensation circuit

•     3G/4G/5G multimode cellular handsets (5G NR, LTE, UMTS, CDMA2000, EDGE, and GSM)

•     Embedded data cards
