HS8298H

The HS8298H is a complete CMOS high-power, high-efficiency transmit module for low cost quad-band TX (GSM850/EGSM900/DCS1800/PCS1900)/dual-band RX GSM/GPRS mobile handsets. Power amplifier, Power controller circuit and switch circuit have been integrated in a single CMOS chip. Internal TX/RX 50Ω matching, DC blocking on TX/Ant and harmonic filtering circuits are integrated, and this eliminates the extra need of external components, simplifies layout and reduces board space as well. The advanced front-end module architecture has been designed specifically to use standard CMOS technology to implement high output power at high efficiency over all the operating conditions. No external compensation for temperature, frequency or battery is another advantage to meet RF performance over various conditions. The module is packaged in a small LGA format (5.25mm x5.3mm x0.82mm).

•     High Output Power

-     34.0dBm(typ.) at GSM850/EGSM900

-     31.0dBm(typ.) at DCS1800/PCS1900

•     High Power Added Efficiency

-     GSM850 41% PAE

-     EGSM900 41% PAE

-     DCS1800 35% PAE

-     PCS1900 35% PAE

•     Integrated Control and Protection

•     VBATT Operating range 3.3V to 4.5V

•     Complete power control solution

•     Advanced CMOS process

•     LGA 5.25mm x5.30mm x 0.82mm

•     Quad-band cellular handsets

•     Multimode Mobile Handset Applications

•     GPRS Class 12 Compliant

•     Portable Battery-Powered Equipment
