HS8358F
昂瑞微 射频芯片 3G功率放大器 HS8358F
HS8358F Power Amplifier Module (PAM) is a fully matched 14-pad surface mount module developed for Wideband Code Division Multiple Access (WCDMA) applications. This small and efficient module covers 824MHz-1980MHz bandwidth operation with a single compact package. Due to high efficiency attained throughout the entire power range with APT operation, the HS8358F extend talk-time greatly. The HS8358F meets the stringent spectral linearity requirements of High Speed Downlink Packet Access (HSDPA), High Speed Uplink Packet Access (HSUPA). An integrated directional coupler eliminates the need for any external coupler.
• Excellent Linearity
• High Efficiency
- 44% at 28dBm
- 14-pad Configuration
• APT Operation Supported
• Large Dynamic Range
• Small, Low Profile Package
- 3mm×4.2mm×0.9mm
• Integrated Directional Coupler
• WCDMA Handsets & Datacard
• CDMA
• HSDPA
• HSUPA
• HSPA+
• NB-IoT
