OM8330-11
昂瑞微 射频芯片 4G功率放大器 OM8330-11
OM8330-11 is a multimode multiband (MMMB) Power Amplifier Module (PAM) that supports 3G/4G handsets and operates efficiently in CDMA, WCDMA, TD-SCDMA, and LTE modes. The module is fully programmable through a Mobile Industry Processor Interface (MIPI).
The PAM consists of a 3G/4G PA blocks for low, high, and mid-bands, and a Multi-Function Control (MFC) block, RF input/output ports internally matched to 50 ohm to reduce the number of external components. A CMOS integrated circuit uses standard MIPI controls to provide the internal MFC interface and operation. Extremely low leakage current maximizes handset standby time. The devices packaged in a small LGA package. (3.0 mm x 3.0 mm x 0.7 mm)
• 6 TX outputs
• Optimized PAE for3G/4G
• Optimized for APT DCDC operation
• Fully programmable Mobile Industry Processor Interface (MIPI) control
• Small package: 3.0 mm×3.0 mm×0.7mm, LGA22 pad configuration
• Multiband 3G / LTE handsets
• WCDMA Bands I, II, III, IV, V, VIII, IX
• TD-SCDMA Bands 34, 39
• FDD LTE Bands 1, 2, 3, 4, 5, 7, 8, 9, 12, 13, 17, 20, 25, 26, 28, 30
• TDD LTE Bands 34, 38, 39, 40, 41
• CDMA2000 Bands BC0, BC1, BC4, BC6, BC010, BC015
